Logotype & Symbol: Free Illustrator Tutorial

Topics Covered in This Illustrator Tutorial:

Recreating a Logo Graphic & Text, Drawing from a Scanned Template

Exercise Preview

Exercise Overview

You've been tasked with breathing new life into a legacy brand asset—a challenge every designer faces. Your starting point is a grayscale Photoshop file containing a scan of the classic AT&T logo. Like most vintage scans, this one bears the imperfections of both the original printing and the digitization process—blurred edges, inconsistent line weights, and possible distortion.

This exercise mirrors real-world logo recreation projects where you'll need to reverse-engineer brand elements from less-than-perfect source material. You'll use Illustrator's vector tools to create a crisp, scalable version that maintains the integrity of the original design while eliminating the artifacts of analog reproduction. This skill is invaluable whether you're working with heritage brands, vintage materials, or client-supplied artwork that needs professional refinement.

Getting Set up

The foundation of any successful tracing project lies in proper template preparation. We'll configure your workspace to optimize visibility while maintaining reference accuracy.

1. Navigate to File > Open and locate logotemplate.psd in your Illustrator Class folder. Illustrator will automatically rasterize this Photoshop file and place it as embedded artwork on your artboard, ready for tracing.

2. Transform this scan into a proper tracing template by accessing the Layers panel. Double-click the thumbnail or opacity indicator to the right of the layer name "logotemplate" (avoid clicking the layer name itself, which only allows renaming). In the Layer Options dialog, activate Template mode and set Dim Images to 30%. This configuration locks the layer to prevent accidental selection while providing optimal contrast for tracing.

3. Confirm your changes by clicking OK. Notice how the template layer now displays with a different icon, indicating its protected status.

4. Establish your working layer by clicking the Create New Layer button at the bottom of the Layers panel. This separation ensures clean file organization and prevents accidental template modifications.

Recreating the Logo

Now comes the strategic work of logo reconstruction. Professional logo recreation requires both technical precision and design judgment—you're not just copying pixels, but interpreting the designer's original intent.

1. Before touching any tools, analyze the entire composition systematically. Study both the template and the reference image at the top of this page to understand the logo's fundamental construction principles.

   Consider these critical design questions: What geometric relationships define the symbol's proportions? Which elements repeat or echo throughout the design? Should you approach this by constructing positive shapes (the black elements) or by subtracting negative space from a base form? Does the logotype use a standard font family that you can identify and modify, or will it require complete reconstruction using the Pen tool?

   Remember that scanned artwork often contains imperfections that weren't present in the original design. Your job is to interpret the designer's intent, not slavishly copy every flaw. Look for consistent curves, parallel lines, and symmetrical relationships that may have been compromised during reproduction.

   A Couple of Hints and Strategies:

   • Symbol Construction: The circular logo symbol works best when built from a perfect black circle with white elements subtracted. Consider using Illustrator's Pathfinder panel to subtract overlapping white shapes—this approach ensures mathematical precision and clean curves that scale beautifully at any size.
   • Typography Approach: If font matching proves unsuccessful, embrace the Pen tool for letterform reconstruction. Alternatively, find the closest available typeface and convert it to outlines using Type > Create Outlines, then refine individual anchor points and bezier curves to match the original's character.

2. Upon completion, implement a thorough quality assurance process:

   • Save your work using Illustrator's native format to preserve all vector properties and editability.
   • Print a proof at actual size to evaluate how the design performs in physical form—digital screens can mask subtle alignment issues.
   • Inspect your output critically, comparing it against both the template and the reference image. Look for inconsistent stroke weights, imperfect curves, or spacing issues that might compromise the logo's professional appearance. Refine as necessary until the result matches the original's visual impact while surpassing its technical quality.
